  3. HDMI/DVI-D to HDMI/DVI-D, VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.4

  4. HDMI/DVI-D to HDMI/DVI-D, VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.4

rev4

HDMI/DVI-D to HDMI/DVI-D, VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.4

$10,000.00

This Virtual Package includes:

  • PCB Gerber Files
  • BOM
  • Source Codes
  • Compliant FW Supplied
  • Packaging design files
  • Enclosure design files
SKU: REV-FOUR-PCB-SC Category:

Product Description

HDMI/DVI-D to HDMI/DVI-D, VGA/RGBHV and YUV/Component with Optical 5.1 and Analog Stereo Sound rev.4

Specifications and Capabilities:

Input

1 x HDMI v1.4 (DVI 1.0 compatible)
12-bit deep color HDMI native support
Automatic Input Format Detection: Digital YCbCr and RGB

Output

Digital HDMI / DVI-D and/or VGA FEMALE output connector, 10 bit analog resolution.
Horizontal shift capability for RGB output mode
■ Enabled with a dip-switch, applied with push-buttons
Output horizontal and vertical sync polarity selector for RGB modes (dip switch)
Digital Output format: Either HDMI or DVI-D
11-bit 225MHz DAC processing (for true 10-bit analog output)
Two separate Internal EDID EEPROM with complete CEA861 extension block, Dip-switch selectable
■ One EDID supports all formats (by default, reprogrammable)
■ The other EDID is up to 1080i, and no 24Hz support (by default, reprogrammable)
Full BTB and WTW support in YPbPb output
Automatically switches color-spaces for both HDTV and SDTV
Precise black levels – no black crush in any standard mode
Integrated RGB Color Space Converter for both RGB-to-YCbCr and YCbCr-to-RGB (both 601 and 709) with true 12-bit accurate data using 14-bit processing
4:2:2 <> 4:4:4 converter with 12-bit accurate data using 14-bit processing
Analog Output format
Either RGB or YPbPr, dip-switch selectable
■ YPbPr requires VGA->3RCA breakout cable
All HD/SDTV formats from 1080p down to 480i, NTSC and PAL
■ Including 1080p @ 72Hz PAL and NTSC (for RGB output only)
■ Including 1080p @ 24Hz PAL and NTSC

Industry-Standard Compliance

HDMI 1.4
EIA/CEA-861E
DVI 1.0

Digital Video Input / Output

Dual integrated HDMI 1.4 cores
Supports DTV resolutions up to 1080p @ 72Hz or 720p/1080i @ 120Hz with 36-bit color depth.
Flexible digital video interface:- 24/30/36-bit RGB/YCbCr 4:4:4- 16/20/24-bit YCbCr 4:2:2- 8/10/12-bit YCbCr 4:2:2 (ITU-R BT.656)

Digital Audio Output

HDMI audio passthrough
Industry-standard S/PDIF output
Supports 2-channel 32-192kHz stereo audio
Supports IEC60958 2-channel PCM
Capable of passing IEC61937 compressed audio (5.1 Dolby® Digital, DTS, etc.)
7.1 Dolby® True HD & DTS Master Audio

Dual purpose audio output connector

SPDIF digital output for 5.1 Dolby/DTS
Analog L/R 2-channel stereo

*No end-user access to decrypted analog video.

3D Features

  • Add HDMI 2D and 3D to ANY TV, Monitor, Proj (even 60hz TV !)
  • Display HDMI 2D and 3D content on Digital and/or Analog display
  • Output in both Digital and Analog Video/Audio simultaneously !
    Therefor acting as an advanced digital/analog splitter.
  • Double and Triple frame 1080p24 material up to 1080p72
  • 3D mode output up to 720p144
  • Dual projectors setup using two 3Dfury modules and passive glasses.
  • Up to 720p288 and/or 1080p144 in dual projectors setup !
  • 7.1 Dolby® True HD & DTS Master Audio
  • Input: HDMI 1.4 (HDCP compliant) input with 3D and Deep Colour support
  • Output: Digital HDMI / DVI-D and/or Component (YPbPr/YCbCr) and VGA (RGBHV) video output
  • Advanced SimulView support (through Glasses and Emitter or through Stream Control)
  • All modes autodetected if possible, otherwise can be forced via button
  • 3-pin mini-DIN Sync Out (for optional emitter)
  • Dynamically create EDID based on Sink EDID parameters
  • Customization settings available through DIP SWITCH and buttons
  • Perfectly and automatically center image in all standard NTSC/PAL component modes
  • Manually adjust horizontal screen position in all NTSC/PAL RGBHV modes
  • Performs Colour Depth Upscaling in all modes (ON/OFF user selectable)
  • Horizontal and Vertical Sync Polarity Inverter included
  • Automatic SD/HD color-space selection
  • Accept third party accessories on its output
  • Improved output cable driver for driving long cable runs (40-50′)
  • Software/Firmware upgradeable through USB
  • Sound output:
    • Analog and Digital Optical (S/PDIF 5.1 Dolby/DTS) through an innovative 3.5mm combo jack and 7.1 DTS-MA & Dolby True HD via HDMI output
    • HDMI audio passthrough

3D Input/Output mode:

  • 2D VIDEO MODE COMPATIBILITY:

    • NTSC 480i/p, PAL 576i/p, HDTV 720p/1080i/1080p

  • 2D OUTPUT:

    • 2D movies: 1080p24, 1080p48, 1080p72 (3Dfury can double and triple frame from 24hz material)
    • 720p60, 720p120 (double frame from 720p60)
    • Passthrough any resolution

  • 3D MODES INPUT COMPATIBILITY:

    • Full 3D HD 1080 (per HDMI) (Blu-ray): 1920 x 2205 24Hz
    • Full 3D HD 720 (per HDMI) (Blu-ray): 1280 x 1470 60Hz
    • Top/Bottom 1080p 24Hz: 1920 x 1080
    • Top/Bottom 1080p 25Hz: 1920 x 1080
    • Top/Bottom 1080p 30Hz: 1920 x 1080
    • Top/Bottom 1080p 50Hz: 1920 x 1080
    • Top/Bottom 1080p 60Hz: 1920 x 1080
    • Top/Bottom 1080i 50Hz: 1920 x 1080
    • Top/Bottom 1080i 60Hz: 1920 x 1080
    • Top/Bottom 720p 30Hz: 1280 x 720
    • Top/Bottom 720p 50Hz: 1280 x 720
    • Top/Bottom 720p 60Hz: 1280 x 720
    • Side-by-Side 1080p 24Hz: 1920 x 1080
    • Side-by-Side 1080p 30Hz: 1920 x 1080
    • Side-by-Side 1080p 50Hz: 1920 x 1080
    • Side-by-Side 1080p 60Hz: 1920 x 1080
    • Side-by-Side 1080i 50Hz: 1920 x 1080
    • Side-by-Side 1080i 60Hz: 1920 x 1080
    • Side-by-Side 720p 50Hz: 1280 x 720
    • Side-by-Side 720p 60Hz: 1280 x 720
    • Frame packed 720p 30Hz: 1280 x 720
    • Frame packed 720p 50Hz: 1280 x 720
    • Frame packed 720p 60Hz: 1280 x 720
    • Frame packed 1080p 24Hz: 1920 x 1080
    • Frame packed 1080p 25Hz: 1920 x 1080
    • Frame packed 1080p 30Hz: 1920 x 1080

  • 3D OUTPUT:

    • 720p60, 720p72, 720p96, 720p120, 720p144 Frame Sequential
    • 720p and/or 1080p for 60hz display
    • 1080p60, 1080p72

    Scaler Features

      • Display HDMI content on ANY HDMI/DVI-D/RGB/VGA/YUV TV, Monitor or Projector
      • Always display any HDMI content at your display max resolution
      • Output in both Digital and Analog Video/Audio simultaneously !
        Therefor acting as an advanced digital/analog splitter.
      • Double, Triple, Quadruple frame 1080p24 material up to 1080p96
      • Double Frame 720p50 and 720p60 into 720p100 and 720p120
      • Transcoder and Scan converter, Toggle 50/60Hz or PAL/NTSC at will.
      • Any input can be up or down-scaled to a specified resolution up to 1080p96 for HDTV
      • Any input can be up or down-scaled to a specified resolution up to 1920×1200 for PC mode
      • 7.1 Dolby® True HD & DTS Master Audio
      • Input: HDMI 1.4 (HDCP compliant) input with 3D and Deep Colour support
      • Output: Digital HDMI / DVI-D and/or Component (YPbPr/YCbCr) and VGA (RGBHV) video output
      • 3 Aspect Ratio Modes (Full Width, Full Screen, Original, read FAQ for more details)
      • Custom porch settings, resolution and refresh rate adjustment through Windows Software.
      • Dynamically create EDID based on Sink EDID parameters
      • Customisation settings available through DIP SWITCH and buttons
      • Perfectly and automatically center image in all standard NTSC/PAL component modes
      • Manually adjust horizontal screen position in all NTSC/PAL RGBHV modes
      • Performs Colour Depth Upscaling in all modes (ON/OFF user selectable)
      • Horizontal and Vertical Sync Polarity Inverter included
      • Automatic SD/HD color-space selection
      • Accept third party accessories on its output
      • Improved output cable driver for driving long cable runs (40-50′)
      • Software/Firmware upgradeable through USB
      • Special software available for Mits RPTV and others 1080i display.



    • Sound output:
      • Analog and Digital Optical (S/PDIF 5.1 Dolby/DTS) through an innovative 3.5mm combo jack and 7.1 DTS-MA & Dolby True HD via HDMI output
      • HDMI audio passthrough

    Scaler Input/Output mode:

    VIDEO MODE INPUT COMPATIBILITY:

    Basically any CEA / VESA input resolution is supported up to 1920x1200x60
    All known SD, HD and Full HD formats are supported including:
    ■ 480p50, 480p60
    ■ 576p50, 576p60
    ■ 720p50, 720p60
    ■ 1080i25, 1080i30, 1080p24, 1080p25, 1080p30, 1080p50, 1080p60

    VIDEO MODE OUTPUT COMPATIBILITY:

    All known SD, HD and Full HD formats are supported including:
    ■ 480p50, 480p60
    ■ 576i, 576p25, 576p30
    ■ 720p50, 720p60, 720p100, 720p120
    ■ 1080i, 1080p24, 1080p25, 1080p30, 1080p48, 1080p50, 1080p60, 1080p72, 1080p75, 1080p96
    All following PC graphics mode are supported in either 50 or 60Hz:
    ■ 800×600, 1024×768, 1280×768, 1360×768, 1440×900, 1600×900, 1280×1024, 1400×1050, 1600×1200, 1920×1200
    ■ Passthrough any resolution
