4:4 HDMI/DVI-D to HDMI/DVI-D PCI
$1,000.00
This Virtual Package includes:
PCB Gerber Files
BOM
Source Codes
Compliant FW Supplied
Packaging design files
Enclosure design files
Product Description
4:4 HDMI/DVI-D to HDMI/DVI-D PCI
Specifications and Capabilities:
SD/HD/Full HD & UHD support.
Up to 4K30 4:4:4 or 4K60 4:2:0.
4 HDMI inputs, 4 HDMI outputs.
Instant Fast Switching without blinking (alterable by the connected display’s capability)
32 viewing combinations.
EDID Management, USB service port for customization needs.
REMIX/CUSTOM and FIXED EDID mode are available.
4-IN 4-OUT HDMI Repeater with Equalizer
Supports 4 HDMI input ports (Port 0/1/2/3) with on-chip EDID RAM for each port.
Support HDMI/MHL dual mode in RX0 port.
Support wide Frequency Range: 25MHz – 340MHz TMDS clock
Supports 12-bit Deep Full HD, Full 3D and 4K2K video.
Supports Standard Audio, DSD Audio and HD (HBR) Audio
HDMI-CEC passthrough
Source Signal Detection in Low Power mode
On-chip Power Regulator which provides regulated 3.0V and 1.6V power
Low stand-by current at power down mode
